Product Description
-
1/2.7” 2MP PS CMOS Image Sensor (6.858cm)
-
25/30fps@1080P(1920×1080)
-
H.265 / H.264 dual-stream encoding
-
DWDR, Day/Night(ICR), 3D-DNR, ROI, AWB, AGC, BLC, HLC
-
2.8~12mm Motorized lens
-
IR Range of 40 Mtrs, IP67, Micro SD Card, PoE
-
Mobile Software: iCMOB, gCMOB
-
CMS Software: KVMS Pro
Product Specification
|
Brand |
CP Plus |
|
Product Type |
Dome Camera |
|
Product Model |
CP-UNC-DA21ZPL4-M |
|
Image Sensor |
1/2.7” 2MP PS CMOS Image Sensor (6.858cm) |
|
Minimum Illumination |
|
|
Effective Pixels |
1920(H)x1080(V) |
|
Bodytype |
Dome |
|
Shutter Speed |
Auto/Manual, 1/3~1/100000s |
|
White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual/Regional custom |
|
Lens |
2.8mm~12mm Motorized Lens |
|
Gain Control(AGC) |
Auto/Manual |
|
Video Compression |
H.265 /H.265/H.264 /H.264H/H.264B/MJPEG |
|
Angle Of View |
Pan: 106°~33°, Tilt: 56°~19° Diagonal: 127°~38° |
|
S/N Ratio |
More than 50dB |
|
Back Light Comp. |
BLC/ HLC/ DWDR |
|
Frame Rate |
Main Stream: 1080P (1 ~ 25/30fps) Sub Stream: D1(1 ~ 25/30fps) |
|
Resolution |
1080P(1920×1080)/1.3MP(1280×960)/ 720P(1280×720)/D1(704×576/704×480)//VGA(640×480)/ CIF(352×288/352×240) |
|
Motion Detection |
Off / On (4 Zone, Rectangle) |
|
Privacy Mask |
4 Area |
|
ICR |
Auto(ICR)/Color/B/W |
|
Roi |
Yes (4 areas) |
|
Bit Rate |
H.264: 32K~6144K, H.265: 12K~ 7424K |
|
Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; ONVIF (Profile S); CGI; Genetec; P2P |
|
Ethernet |
RJ-45 (10/100Base-T) |
|
User Account |
20 Users |
|
Smart Phone |
iPhone, iPad, Android Phone |
|
IR Range |
IR Range of 40 Mtr., Smart IR |
|
Micro Sd |
FTP; Micro SD card (support max. 256 GB) |
|
Operating Temperature |
-40°C to 60°C (-40°F to 140°F)/less than ≤ 95% RH |
|
Power Source |
DC12V, PoE (802.3af) |
|
Power Consumption |
< 6.3W |
|
Weatherproof Standard |
IP67 |
|
Dimension |
98.1 mm × Φ122 mm |
|
Weight |
0.38Kg |
|
Warranty |
As Per Manufacturer Terms and Condition |
